Sunday, May 29, 2016
Issue #495, Here’s Exactly How You Do It: Imaging Jupiter (or Mars or Saturn)…
|Jupiter under poor seeing with the setup described herein...|
I’ve posted articles concerning planetary imaging more than once in the past, but in them I’ve always given you alternatives, “You can buy software A or software B. You use telescope A or telescope B, you can try camera A or camera B.” But I’ve come to realize people getting started in photographing the solar system may, at first anyway, just want to be told what to do. What exactly can you buy and download to image the worlds of the Sun and how exactly you use it. No choices, just a simple system that works.
So, before you write me to ask, “Well, how come you didn’t mention this telescope or this camera or this software?” I know there are alternatives to the setup I am going to describe. What I am doing is telling about a system that will work, and that you can modify as your experience grows.
One last caveat: getting good pictures of the planets depends on one thing more than anything else: seeing. Atmospheric steadiness. That trumps telescopes and cameras of the most expensive sort. If you live in an area with constant poor seeing, there’s only so much you can expect. Take heart, though. Most people don’t live in locations like that. Most peoples’ seeing steadies down occasionally at least. Keep an eye out for the sort of weather that will bring steady air, like stagnant high pressure domes, and be prepared to take advantage of it.
How much will it cost to get into planetary imaging? Not much if you already have a suitable telescope and mount. If you don’t, expect to spend as much as 1000 – 1500 bucks for a usable scope and mount, or as little as 300 – 400 for a telescope alone.
OK, let’s get to it. First step is accumulating the gear you need…
I don’t make a secret of the fact that I don’t use SCTs as much as I used to, but when I go after the Moon and planets, I go back to them. And specifically the 8-inch Schmidt Cassegrain. It brings one important thing to the table. Lots of focal length. You can get to the 4000mms of focal length that is where you begin for high resolution Solar System pix with the addition of a simple 2X Barlow. One also has enough light gathering power to make exposures reasonably short, a must if you are to defeat seeing. Finally, a Meade or Celestron 8-inch SCT is short and light and does well on less expensive mounts. Get an 8-inch SCT.
|Meade flip mirror on SCT...|
Naturally, you’ll need a driven, tracking mount. You’ll also find goto speeds things up a lot. You wouldn’t think it would be difficult to get Jupiter or Saturn in the field the old fashioned way with a finder, but it is. It’s can be hard even if you have a flip mirror. A modern goto mount can put your quarry on the small chip of a planetary cam every stinking time.
Alt-azimuth or equatorial? A driven alt-azimuth mount is usable, but even if you take pains with the goto alignment (a good goto alignment improves an alt-az mount’s tracking), the tracking will be worse than that of a decently polar aligned GEM. A German equatorial mount makes life easier, so use one. Luckily they are cheap. A goto CG5 style mount, whether the ASGT Celestron CG5 (used only), the newer VX, the Meade LXD-75 (used only), or the new player, the Bresser mount from Explore Scientific, are inexpensive new and very inexpensive used. So, get a CG5 class GEM.
The requirements for a planetary cam, the basic requirements, are two: a small chip and small pixels. Quite a few cameras in all price ranges fulfill those requirements, but few do it better than the ZWO Optical ASI120MC. The “C” stands for color, as in one-shot color, which will make your life easier when you are starting out. Just because this camera is inexpensive new, less than 200 dollars, don’t think it is a slouch when it comes to performance. It will deliver up to 100fps, frames per second if you keep the size of those frames small (see below). So, get an ASI120MC.
You’ll need to double your SCT’s focal length by placing a Barlow lens ahead of the camera. Which? Luckily, I’ve seen very few poor quality Barlows of late. My choice for you is good, but it is also cheap, the famous Orion Shorty. I’ve used one for years and there is no downside to it.
You don’t need too many, but you need some. First and foremost, you need a flip mirror to make initial centering of planets easy, even with goto. This is a special star diagonal with a camera port on its rear and a mirror that can be flipped up and down. Flip it down to center the target in an eyepiece, flip it up to send the images out the rear port to your camera. Flip mirrors can be adjusted so that what’s centered in the eyepiece is centered in the camera, and what’s in focus in the eyepiece is in focus in the camera. Which one? My choice is the SCT specific Meade flip mirror, but it’s apparently no longer being made. That being the case, get this Vixen flip mirror; it will work fine, but it requires the purchase a 2-inch visual back for your SCT if you don’t have one.
Since planet-cams must be used with a computer, you’ll need one. Any modern PC will do; image acquisition and processing software is much easier on computer horsepower than a modern game like Doom, for example. You’ll either want a Windows PC or a Mac that can run Windows software, and naturally the computer should be a laptop since you’ll be using it outside. My choice is the simple and reliable Toshiba Satellite.
You’ll need to install two programs on that computer. One to operate the camera, and one to process the resulting .avi movies into stacked still frames. For camera control, get FireCapture. It’s free, and while it does tons of stuff, up to and including generating ephemerides and guiding a telescope mount, it is easy to use in simple point and shoot fashion. Its user interface is clean and simple, and it includes a camera simulator so you can play with it indoors. Yeah, get FireCapture.
When you shoot planets, you shoot .avi motion picture files. When done, you stack the (good) individual frames of those movies into finished still pictures and perform processing functions like sharpening the resulting stills and adjusting their histograms (contrast and brightness). The program that will do that is another piece of shareware, Registax. It is mature and easy to use in a basic fashion.
Odds and Ends
You’ll need an IR block filter for a one-shot color camera or images will be way too red, but the filter that comes with the ZWO camera is quite sufficient. All else you’ll need to buy is a longer USB cable, since the one that ships with the camera is a bit too short. Get a 10-foot USB 2.0 AM-BM cable (from your local BestBuy perhaps).
|Exposure Controls on FireCapture...|
Putting it together
The rest of this is going to be surprisingly short and sweet. To begin, set up the telescope as you normally do, but with the flip mirror on the rear cell instead of the normal diagonal. Use a crosshair eyepiece in the flip mirror, one that will yield a power of about 160x, a 12mm f/l eyepiece, that is. The Barlow goes into the camera port and the camera is inserted into the Barlow via its included 1.25-inch nosepiece. You can hook up the camera’s USB cable now if you like or wait till you are done with the mount alignments. You might also want to connect a serial cable to the mount if you want to be able to adjust the telescope’s aim with the computer.
OK, next you’ll either polar align or goto align. If you are using a Celestron mount, I suggest you do the hand control’s built-in AllStar polar alignment routine to ensure good tracking. To do that, you’ll need to do the goto alignment first. If you are using another brand of mount, you’ll normally do a polar alignment first. That doesn’t need to be a drift alignment, but should at least be a careful alignment with the GEM’s polar scope. If the hand control has a polar alignment routine like Celestron’s, use it.
Now, goto Jupiter (or Mars or Saturn or the Moon) and center the image in the flip mirror using the reticle eyepiece. At the computer, bring up FireCapture. There are a heck of a lot of options, but we only want to use the program in the very simplest manner and we’ll mostly be using the Control (exposure) section on the upper part of the sidebar. Adjust the gain slider there until it’s at about 75%; that will prevent images from showing the odd artifacts that can result from lower gain settings. Then, adjust the exposure controls until the planet looks almost bright enough but not quite, so that it looks just slightly underexposed.
|All stacked in Registax...|
Next, center the planet precisely. If you set up your flip mirror correctly, Jupiter should be in the frame, but probably not centered. Center it either with the HC or with an onscreen HC. If you have ASCOM installed on the laptop, use its virtual HC for centering. Just go to ASCOM in the settings portion of the sidebar by clicking the little ASCOM icon, check “initialize telescope interface,” and select the mount (and check “show hand control”) as per normal with ASCOM. If that sounds too complicated, just use the real HC for centering. An extension cable is helpful for that so you can sit at the computer when using the HC.
Focus up precisely. Again, if you set up the flip mirror correctly, Jupiter should be close to being in focus, but probably not exactly in focus. One help here is Motofocus. I had JMI’s Motofocus motor on my old Ultima C8, Celeste, and what a joy it was to sit at the PC and watch the display while focusing with a remote control. Otherwise, trot to the scope, adjust focus a bit, squint at the computer, and repeat as needed till Jupe is as sharp as you can get him (if there’s a Galilean Moon in the field, that’s a great focusing “tool”).
Finally, decide if you want to use FireCapture’s ROI, “Region of Interest” feature or not. If you engage this by clicking ROI in the “Image” portion of the sidebar (very top), and have selected “Jupiter” in the exposure section, Firecapture will crop the frame to a size just big enough to contain Jupe. That will allow the program to deliver much higher frame rates than you’d get at the ZWO’s full resolution. As long as tracking is good enough to keep Jupiter in the field for a minute to a minute and a half, use ROI.
There are two other settings you need to check. Make sure “debayer” is NOT checked in the Options section of the sidebar. As you may know, one-shot color cameras use red, green, and blue filtered pixels to produce color images. Normally, these pixels are combined on the fly to make a color image, they are “debayered” as you shoot. FireCapture, however, allows you to forego debayering, to shoot the avis as, basically, black and white images, and debayer them, convert them to color, later. This saves computer processing power and allows for a higher frame-rate. Also, check in the capture section to make sure "avi" is selected as the file type.
That’s the preliminaries. Now, just click the record button in the Capture section of the sidebar, and record some Jupiter movies. How long? About 1-minute is pretty good, especially if you are using ROI. That will give you plenty of frames to play with but not result in huge files that can be a problem. Shoot plenty more sequences, aiming for getting footage during the best seeing (best circumstances are shortly after dark with the planet above 30-degrees). When you’ve got some sequences that appear to capture the planet when it’s steady, you are done.
Next morning, the first task is to convert the .avi movies to color. Do that using the Debayer app in the FireCapture directory (put a shortcut to it on your desktop, since you will use it frequently). Open the little program, leave all its settings at their defaults, and select and then debayer all the .avi files. Debayer will place color versions of the .avis in the capture directory of FireCapture (you can specify the directory in FireCapture’s setup section before you do your captures).
Now comes stacking the best frames from the sequences with Registax. You will more than likely be a little daunted when you open the program for the first time. Don’t be. There are lots of options and adjustments, but you really only need to perform a very few actions to use the program in the most basic fashion:
- 1. Click “Select” (button on the upper left of the display) and choose the first debayered file. If Registax asks if you want to process it in color, respond “yes.”
- 2. Click the Align tab (below select), and push the “Set Align Points” button.
- 3. Click the Align button.
- 4. Click the Limit button when the align process is done.
- 5. Click Stack.
- 6. When stacking is finished, click “Save Image.”
- 7. Click the Wavelets tab. This is where it gets interesting. The famous Registax Wavelet filters will reveal details you wouldn’t dream were in the stacked image. How do they work? That’s a story for another day. For now, just check the boxes and adjust the sliders as shown here. This is a good starting point. Click “do all,” and see how the image looks. If it looks over processed, try backing off the sliders some.
- 8. There is no “8;” you are done. If you like, you can process Jupiter further with Photoshop or the program of your choice. Don’t have an image processing program? Registax has image processing tools. They are not as easy to use as those in Photoshop, but they work.
Sunday, May 22, 2016
Issue #494, The Messier VII: The Greatest
Before we get to the Great Nebula, let’s talk about “how.” We’ve talked about why novices (or anybody else) might want to take on the Messier list, and we’ve talked about “what,” as in what sort of telescope to use on these deep sky wonders. Now we will address “how” as in “How do you look at ‘em?” What are some tricks and tips for seeing as much of these legendary objects as possible?
The most important thing you can do to improve the appearance of the Messiers, the galaxies and nebulae especially? Naturally, “get to a dark site.” But what if you don’t have a dark site? Or want to observe more often than on once or twice a month runs at a club dark observing location? You can to some extent darken your backyard sky.
The easiest way to do that is with a trick many novices—and more than a few old hands—don’t know: increase magnification. The problem with seeing dimmer objects from the backyard is one of contrast. There is too little contrast between Messier object and the sky background in the eyepiece. The sky is nearly as bright—or as bright—as the M, and the deep sky object is rendered invisible or nearly so.
How do you fix that? Bump up the magnification. Increasing power spreads out the background skyglow, making it less intense. It will also dim the Messier, but often it still provides increased contrast and improves the view. Sometimes a lot. Experiment with a variety of magnifications on each object, but what you want is a power that dims the background but still leaves sufficient space around the object. If you kick up the power so much that the DSO fills the field, there will, again, be a lack of contrast. There will not be enough dark sky around the object to provide contrast.
Another way to darken the sky is to use Light Pollution Reduction (LPR) filters. I have an in-depth article on the subject of deep sky filters coming up in the August issue of Sky & Telescope, so I will refer you to that. Here, I’ll just say filters can make the difference between seeing and not seeing dimmer nebulae.
The next two tips have to do with physiology of the human eye and brain. The most important of the two is called “averted vision.” You’ll find that when you look off to the side of a faint object, look away from it instead of directly at it, you see dimmer features. That’s because looking off to the side of an object brings the eye’s dim light receptors, the rods, which are located around the retina’s periphery, into play.
At first it may feel odd or awkward to look away from the quarry instead of directly at it, but with a little practice you’ll get used to that. Under some circumstances, averted vision may allow you to see two or even more magnitudes dimmer than looking straight at the target and employing only the eye’s cones, the bright-light color receptors.
Jiggling the scope won’t give as much of a gain as averted vision, but it will still yield some improvement. The human eye-brain has an easier time seeing moving objects than stationary ones. That is probably evolution at work. Being able to see moving objects well—like a stalking leopard—would be a survival mechanism. So, tap the scope tube lightly, introducing some vibration, and you may be able to bring home details that were formerly invisible.
What can improve the performance of your eyes even more, perhaps, than the two previous techniques? Allowing them to become as dark adapted as possible, allowing your eyes’ irises to open up as much as possible. Yes, the sky is bright from the backyard, but if your eyes could obtain some dark adaptation, you would see more. What prevents that isn’t really the bright sky so much as it is ambient light, light from nearby sources. Your porch light, the neighbor’s yard light, etc.
What you want to do is rig up some means of shielding yourself and your telescope from intrusive ambient lights you can’t shut off. You can build light shields to shade the scope—I used to construct muslin covered stage flats for that purpose—or you can go simpler and more portable with a sheet of black cloth. A square of black nylon draped over your head can work wonders. What do you do to retain your night vision when you aren’t at the eyepiece? You could try Orion’s silly-looking red-tinted goggles, but cheaper and perhaps more effective might be an eye-patch from the drug store.
Finally, keep that bad ambient light out of the telescope. Most refractors and catadioptric telescopes have dew shields sufficient to keep ambient light out of the optical system. Newtonians are another matter. Modern fast Newts typically don’t have much tube ahead of the secondary mirror, so rig up a tube extension of black material of some kind—plastic, cardboard, whatever—to keep stray light off the secondary mirror.
Check the rear of a reflector, too. The primary cell may have some openings—a good thing where cool down is concerned—which can admit light reflected up from the ground. Rig up a cardboard baffle you can tape or Velcro over the rear of the tube to keep ambient light out of that end of the OTA when cool down is done.
With this arsenal of observing hints and kinks in hand, let’s tackle the next group…
M42 The Great Nebula
And great it most assuredly is. Along with the top globular star clusters of summer, M13 and M5, this is probably the greatest, most spectacular Messier of them all. This HII region, this emission nebula, shines with an integrated magnitude of 4.0, so, despite a size of at least 1-degree 30’ x 1-degree, it is seriously bright. It is, in fact, easily visible naked eye even in the city as the slightly fuzzy middle star in Orion’s sword.
Finding? Since it's a naked eye object, once you know what that fuzzy star represents you’ve found it. As I discovered when I was a little bitty kid with a 4-inch Palomar Junior Newtonian. I was hoping to get a copy of Norton’s Star Atlas “soon” so I could begin seeing deep sky wonders, but to my delight one cold December night, I found star charts are not needed for all Ms. I got curious about that funny star in Orion’s sword, pointed my little telescope to it, and there—OHMYGOD—was the Orion Nebula in my 1-inch war surplus optics Kellner eyepiece.
I won’t reiterate the descriptions of M42 found in a thousand books. I’ll just point out a couple of particulars I don’t hear much about. Yes, the nebulosity is great. Yes, there’s the Trapezium and the other fascinating stars enwrapped in that nebulosity. But what I tend to look at/for more than those things these days are the dust lanes and the nebula’s color.
Up the magnification and start exploring the area of the “fish’s mouth,” the dark bay in the nebula near M43, the companion nebula. This area is criss-crossed by many brownish (in images, anyway), dusty tendrils, and tracing them out in the eyepiece can be a fascinating pastime.
Color? Oh, yeah, I know the party line, “M42 may occasionally appear faintly green in medium aperture telescopes, and large aperture reflectors can sometimes show brown tinges that represent the nebula’s pinks and reds.” That’s true under normal circumstances, but on special nights, and I am not quite sure exactly what makes some nights special, M42 can literally appear stoplight green. Not faint green, but bright green. In an 8-inch or even smaller telescope.
How about trying Light Pollution Reduction filters on M42? I never use them much on Orion. Even in light polluted backyards it holds up well thanks to its brightness, and I prefer its look without an OIII or UHC filter. One of those may be of use when you are seeking fainter details, however. Start with the UHC.
M43, M42’s little buddy, is a smaller comma-shaped patch of nebulosity surrounding the magnitude 6.75 variable star Nu Orionis. M43 subtends 20.0’ x 15.0’ and glows at magnitude 9.0 (that’s the value usually given, but the central area is brighter than that). Not only is M43 interesting in and of itself; it’s a good indicator of the quality of your sky. If you can make out the comma shape easily in a medium aperture scope, you’ve got a good night ahead of you.
What’s to see here, about 10.0’ northeast of the main Orion Nebula? Quite a bit beyond the nebula’s basic shape. Under good skies with a magnification of 250-300x, there are plenty of details available. This, as above, is the area of dusty clouds, and you’ll see them encroaching on the south-southeastern edge of the nebula. You’ll also see the comma’s edges are wispy and complex and deserving of considerable attention. Like the main nebula, I’ve never thought that an LPR filter of any type improved the appearance of M43.
Ah, yes, the good, old Beehive, one of two Messier open star clusters in Cancer. M44, AKA “Praesepe” (“manger”), is a bright one, glowing with a combined magnitude of 3.10. Alas, it is also a large one, extending 1-degree 10’. That makes it proper fodder for big binoculars or a richest field telescope, not something like an f/10 C8. You need considerably more than 1-degree of field to make this one look good, you need a couple of degrees in order to put some empty space around the cluster’s stars.
If you can see the dim constellation Cancer the Crab, you are in like Flynn when it comes to finding. M44 lies in the middle of the triangle formed by Eta, Gamma, and Delta Cancri. If these stars are difficult to make out, it’s still easy enough to locate the target. Just point the telescope in the general area where the center of Cancer is or should be, and your 50mm finder should reveal the cluster without a fuss. In fact, it’s easy to see naked eye from medium dark sites on transparent evenings. In the olden days, people gauged the weather by the appearance of the Beehive. If it was easy to see, nice days were ahead. If not, storms were coming.
When you are on the correct spot, a 6 – 8-inch RFT will show a loose group of about 40 – 50 suns arranged in a slightly oval shape. 70 – 80mm binoculars will real maybe half that number. To me, M44 always looks slightly yellowish, which is understandable given the group’s fairly advanced age (for a galactic cluster). It is rife with red giants.
Don’t put that RFT or binoculars away. The next one is another big one, M45, the famous Pleiades, the Seven Sisters, the daughters of Atlas. Just about everybody has seen this huge (1-degree 50’) and bright (magnitude 1.2) galactic (open) cluster. Almost all my freshman astronomy students know it, though they usually think what they’ve seen is the Little Dipper thanks to the group’s brighter members forming a slightly squished dipper asterism.
Since you won’t have to hunt M45, you can give this group plenty of telescope time. In my old StarBlast RFT or my even older Short Tube 80 refractor, the Pleiades were simply stunning. Even an 80mm telescope brings in hordes of dimmer suns in addition to the bright sapphires that are visible naked eye. There’s something to be seen here in addition to cluster stars as well: reflection nebulosity.
The nebulosity, which is brightest around the cluster star Merope, thus giving it its name, “The Merope Nebula,” is extensive, but it is also dim in the way that only reflection nebulosity can be. It’s easy to image, as in my picture above, taken with an 80mm APO last autumn, but seeing traces of it visually requires a dark site and good transparency. Even then, it’s hard to be sure whether you’re seeing the nebulosity or not. The time-honored analogy is “baby’s breath on a mirror” and that is true in spades. By the way, the Merope Nebula does not represent the remains of the cloud that formed the star cluster; it’s just an area of dust and gas the group is currently moving through.
Y’all know I love bonus objects, deep sky objects with another deep sky object close at hand. In this case, really close at hand. M46 is a nice enough open cluster, mind you. 50+ stars are visible in an 8-inch as a rich group 20.0’ across shining with a combined magnitude of 6.10. On the other hand, the cluster is in an obscure constellation (for novices), Puppis, and is a smidge low for more northerly observers at a declination of -14. There’s that bonus, though, and that makes M46 over the top wonderful.
First you have to find M46. As always, the most efficacious method is just to punch in M-0-4-6 on the hand control. Can’t do that? It forms a long triangle with Eta Monocerotis and Sirius, and you really won’t need much more guidance than that. Under slightly putrid skies it still shows up as a smudge in a 50mm finder. Just don’t confuse it with M47, which is only 1-degree 20’ to the northwest. If the cluster in the eyepiece has a wide range of star brightnesses, with a couple of really prominent ones, you are on M47, not M46.
The cluster itself is a nice one, a basically round and rich group that can show as many as a hundred stars to a 12-inch telescope. There’s a small range in star brightness, most of them being of magnitudes 7 – 9, and that gives the group a substantial, solid looking form; it is well detached from the background. It’s little NGC 2438 that is the prize here, however.
NGC 2438 is a small, 1’10” planetary nebula that looks like a perfect miniature of the big ring, M57. While it’s somewhat dim at magnitude 11.7, the small diameter keeps it easy for small aperture telescopes. I’ve been able to prise it out with an 80mm refractor at 150x. If you’re having trouble finding it, looks for a funny-looking double star about 5’ north of the clusters center. The double looks funny because the planetary nebula is involved with it.
M47 is good, fine, alright, but to tell you the truth, I’d seldom look at it if it weren’t for nearby M46. It’s an OK, cluster, but just OK. Because of the large brightness range of its stars—there are several magnitude 4 – 5 suns in the field—it just doesn’t look as nice to me as M46. The brightness range makes it appear sparser than it actually is, and it is less rich than M47 to begin with.
If you can locate M46, you can locate M47. In your 50mm finder, it will be the cluster to the northwest, and will look brighter given its magnitude of 4.40 coupled with a modest size of 25.0’. Still not sure? It is the group that appears more resolved in a 50mm finder.
When you are on M47, you’ll note it’s basically shapeless, but that the bright stars at its center form a dipper shaped asterism, sort of like a miniature Pleiades or an M39. The view is similar in 8 to 12-inch telescopes, with about 30 dimmer stars being visible in addition to a dozen or so brighter members.
Hydra’s M48 is similar to M46 in that its stars have a fairly narrow range of brightness. It is somewhat brighter than M46, with an integrated magnitude of 5.8, but is not nearly as rich in my 8-inch. Still, not bad, not bad at all. What most novices will find challenging about this one is not looking at it, but looking for it.
If you don’t have goto or digital setting circles, the best bet is to use a half degree long line of three stars aligned northwest/southeast as a signpost. 1 Hydrae, C Hydrae, and 2 Hydrae are located 4-degrees 15’ northeast of Zeta Monocerotis, are in the magnitude 4.5 – 5.5 range, and stand out well in a finderscope. M48 is 3-degrees 15’ northwest of the three stars, and should show up without a hassle in a 50mm finder.
In the eyepiece, you’ll see a scattered, strongly elongated group of about 30 stars. It would be pretty ho-hum if not for the line of bright(er) members that crosses the center of the group. That line of stars, and a couple of arcs of suns also involved in the cluster at least make it somewhat interesting.
Now for something entirely different to end on, a Virgo galaxy, M49. It is bright and impressive for a galaxy, having a magnitude of 8.3 and a size of 10.0’, just right to be easily scarfed up by a 4-inch or even smaller telescope. No, there’s not a lot of detail to be seen, but it is a galaxy that is easy to run down from the backyard. The only problem is how to run it down.
M49 lies in the galaxy-rich wonderland, the “Realm of the Nebulae” between the arms of Virgo. The only saving grace here is that it lies well to the south of the densest area. There are numerous NGCs nearby but no adjacent bright Messier galaxies to confuse you. Still, it’s not easy the first time you undertake to navigate the Virgo Cluster with finderscope and chart. What I used to do before computers was “galaxy hop.” I’d use a wide-field Erfle or, later, a Nagler eyepiece, start at the Star Vindemiatrix, and literally hop from one galaxy to the next, using them as stepping stones to my destination.
When you are finally there, however you get there, don’t be too disappointed. What will be in the field is something that looks a lot like an unresolved globular cluster. A bright core and a hazy, round outer envelope. The better the sky, the bigger the envelope. This is a Hubble Type E2 galaxy, an elliptical galaxy, so there is simply not much detail beyond that to be seen. There are some nearby small 13th magnitude galaxies that can be visible in 12-inch and larger telescopes, and there are a couple of magnitude 13 range stars close by—nope, sorry, you have not discovered a supernova—but that is it.
And here we are approaching the halfway point in the list already. That is reason enough to put on the brakes. These objects are made to be savored. I won’t dash through them when writing about them, and you shouldn’t dash through them when viewing them, especially for the first time.
Sunday, May 15, 2016
Issue #493, Scrimmaging
I make no secret of the fact I don’t do as many star parties as I used to. Oh, I am still happy to fly in to the most distant events to give talks to my fellow amateurs in my capacity as an astronomy writer/raconteur, but when it comes to loading my Toyota 4Runner with a ton of gear and driving long distances to dark skies to observe? Not so much anymore.
There are various reasons for the above, including the fact that I can now do deep sky astrophotography from my backyard. And who knows? My current aversion to driving to Timbuktu, often to do nothing more than look at the undersides of clouds, may be a temporary thing. Be that as it may, at this time I prefer to stick close to home.
“Close to home” doesn’t just mean I decline to drive two or more days to get to the Texas Star Party or one of the other big events out west. It means I’ve even cut back on my trips to Chiefland, Florida and the Chiefland Astronomy Village, which is a mere six hours away.
Still, I sometimes want darker skies for imaging or visual work than what my backyard or my club’s fairly decent dark site offer. Luckily, one of my favorite star parties, one of the longest running star parties in the USA, the Deep South Star Gaze (formerly the Deep South Regional Star Gaze), is only three hours from home and has skies that are actually slightly better than those of Chiefland.
It gets better still. While the DSSG has always been held in the fall, for some years we’ve also been doing a less formal spring version, the Deep South Star Gaze Spring Scrimmage. No speakers, no door prizes, just observing. There is a meal plan, however, and the small number of attendees compared to in the fall, 20-30 rather than 100-150, means there’s no problem getting one of the small motel rooms in the site’s, the Feliciana Retreat Center’s, Lodge.
|Set up Thursday afternoon...|
What lights my fire about the Scrimmage is that I get a crack at the summer/late spring objects under dark skies at a location with excellent amenities. That and being able to hang out with my long-time Deep South buddies. I’ve been doing the Spring Scrimmage ever since I retired from my engineering gig, with 2016 being my fourth one.
The only problem with the Scrimmage is the weather in this part of the country in the springtime. Year One, I got one night. Year Two I got one good night and part of another. Year Three,last year, I didn’t get squat. That’s just part of the amateur astronomy game, and I can have a good time under less than good skies, but for once it didn’t seem weather would be a problem. This year, the forecasts were unanimous that we’d have clear skies for all three nights of the event, which would begin on Thursday, May 5th. Yee-hah!
How did I feel about the trip as I loaded up Ms. Van Pelt, the 4Runner, late Wednesday afternoon? I was pumped. It wasn’t just the amazingly beautiful and uncharacteristically cool, crisp, and clear weather either. I was in the mood to do a star party, more in the mood than I’d been in about a year. I worked with a will to get all the astro-stuff in the truck, almost—but not quite—whistling a happy tune.
My current star party rig is my SkyWatcher 120mm Pro ED refractor, Hermione—this would be her first trip to really dark skies—and since I would be imaging, the mount she’d be riding would be my Celestron CGEM. I had the usual ton of other junk to load as well—cables, cameras, gear cases, computer, etc., etc. By the time I was finished, I was more than ready to call it an early night—well, after a glass or two of Merlot and Arrow on the TV.
The only slight bring down was that some business I needed to conduct Saturday (including attending Free Comic Book Day, which wasn't a bring down at all, natch), meant I’d decided to scale the trip back from three nights to two. I’d be onsite Thursday and Friday nights and go home Saturday morning. Actually, that wasn’t really much of a bring down, since lately two nights at an event seems just about right for me.
Thursday morning’s trip to the Feliciana Retreat Center, which is nestled in the backwoods of northeastern Louisiana near Norwood, was uneventful in the extreme. Miss Dorothy normally does not attend this event, so I was by myself and passed the time listening to an audiobook of one of my favorite Stephen King Novels, The Girl Who Loved Tom Gordon. I was about halfway through the CDs, to the point where poor little Trisha is wandering the lost pathways of New Hampshire's chimney, when I drove onto the spacious observing field slightly before twelve p.m.
How was gear set up? Not too bad. I’ve erected my EZ-Up tent canopy more than a few times by myself, and have gotten pretty good at that, but it was still nice when my old friend Walt stopped by to lend a hand. Two of my other long-time Deep South pals, Barry and Ron, had also arrived and were, like me, getting their telescopes put together, said telescopes being, like mine, refractors.
While this was just a small event, sure, I thought it was telling that lens scopes outnumbered everything else by at least two-to-one. I suppose the current incredibly reasonable prices for high quality imported Chinese ED scopes is what is tipping the table back in favor or refractors again.
The CGEM is heavy enough that it is not exactly a pleasure to mount on its tripod, but it isn’t that bad, and when I know I will be able to leave it set up for a couple of days, not having to take it down and cart it home at the end of one evening, it doesn’t seem bad at all. Hermione only weights 11-pounds and easy to get on the CGEM and very steady on it. What really made putting the telescope and tent canopy together more pleasant than usual? Temperatures in the lower 70s, something rare for us in May. I got all the other junk arranged under the EZ-Up and proceeded to the Lodge to get settled in my room.
The Lodge features motel-like rooms that are clean but not exactly spacious. Nevertheless, Center management feels the need to cram a bunk bed AND a single bed into almost every one, and there’s not enough space left over for even a desk on which to put your laptop. The air-conditioners work, but are old and noisy and on their last legs. So, no, not up to the level of even a Days Inn, but a heck of a lot more comfortable and cleaner than the average star party chickie cabin for sure. I bring along a small folding aluminum camp table for the laptop, and I am good for a couple of days.
What the Lodge lacks as far as rooms, it more than makes up for with its beautiful, modern-looking dining area. This part of the Lodge also features workable (if not hyper-speed) wi-fi and is where most folks hang out during the endless days. What’s the biggest pain with a spring star party? The freaking Daylight Savings Time. It’s a long, weary old stretch from afternoon to eight p.m. when you can at least get your telescope aligned. I spent the hours before supper in the dining area Facebooking, Cloudy Nighting, and QRZ.com-ing.
One thing that has made the wait for dark a little easier to take in past years has been lunch. That tends to break up the day a bit. Alas, the last couple of times it’s been two meals a day, breakfast at nine and an early (4 p.m.) supper, so the days do tend to drag badly.
|The dining room.|
When supper came, I was reminded of one of the best things about DSSG—the food at Feliciana. Thursday’s meal, brisket, was outstanding. No, I didn’t dare eat the mega-carb loaded baked potato casserole, but the excellent brisket and a large salad from the salad bar were more than enough to fortify me for the night to come.
Out on the field as the Sun slowly, ever so slowly, began to sink, I didn’t have a lot to do. I’d already installed the DewBuster heater strips on Herminone’s objective and the 50mm Orion guide scope. All that remained was to position the computer on the observing table under the EZ up, hook cables to it and to the imaging camera, a Canon 400D, and the guide-cam, a QHY 5-LII, and get the mount aligned.
I had an ace up my sleeve in that regard, the Celestron StarSense alignment camera/system. This does a goto alignment on the CGEM without my intervention, and is as accurate, easily, as the best “manual” goto alignment I can do. Even better, the StarSense encourages me to do two iterations of the AllStar polar alignment routine, since I don’t have to redo the time consuming 2+4 goto alignment after each polar alignment. I just tell StarSense to do another automatic goto alignment and twiddle my thumbs while it does.
What’s the StarSense alignment procedure like? I temporarily remove the guide scope, placing it in my TPI spreader's tray, and mount the StarSense camera in its place. Light off the mount, tell the StarSense HC to do an auto-align, and away she goes. In about three minutes the mount has gone to multiple star fields, has done plate-solves, and I am goto aligned.
After that, if I am imaging, I do an AllStar polar alignment, which works almost the same with the StarSense as with the old hand control. Point at a star, the mount slews off, re-center it with the altitude and azimuth adjusters. The StarSense HC then does another goto alignment and once that’s finished I am done (or if I want the most accurate polar alignment I can get with AllStar, I do another iteration of that followed by another auto-align).
When dark came on Thursday, I remounted the guide scope and focused it by watching the brightness value of a medium bright and non-saturated star increase on the auto-guide program’s, PHD2’s, display on the laptop. By the way, if you have not yet switched from the old PHD to PHD2, you really should. The new version is better.
|M3 and little NGC 5263...|
To focus the main scope I get a bright star, Arcturus Thursday night, as small as I can get it and then sharpen up dimmer background stars by eye. Nebulosity, my camera control program, allows me to focus on a nice big image on the laptop rather than squinting at a tiny picture on the DSLR’s display, and that makes focusing so much easier, y’all. For final tweaking, I engage Neb’s fine-focus mode, clicking on a star on the laptop display, and twitching focus till the FWHM number Nebulosity displays is as small as I can get it.
The rest of the evening was rather anti-climactic. This would be a night of Messier globs, with the first on the list being that gem of spring, Coma’s M3. When the CGEM stopped slewing, M3 was dead in the center of the frame, but I nudged it off center a bit so as to also include a cute little galaxy, NGC 5263, in the picture. Started PHD2 guiding, and after giving it a little while to settle down, I dialed up 180-seconds of exposure with Nebulosity and told the program to acquire 25 subs with the Canon 400D.
After that, there really wasn’t a heck of a lot for me to do. I would check in with Nebulosity and PHD2 occasionally, but my intervention was never required; the software just kept clicking off sub-frames and taking and subtracting darks. I’d brought along a pair of 10x50 binoculars and spent some time scanning the sky. When I tried of that, I checked out my friend Beth’s new 12-inch SkyWatcher collapsible-tube goto Dobsonian. I am glad I downsized to a 10-inch dobbie, but must admit Beth’s scope was delivering impressive images.
So it went for the balance of the evening. I’d choose a new target from the list on my new observing planner program, Deep-Sky Planner 7, switch to my current fave planetarium app, Stellarium, click on the next target, send the mount there with a CTRL-1 key combo, and get another sequence underway. I would then set off wandering the field again. I did take a couple of breaks and walk back to the Lodge for hot coffee. Can you believe it? I forgot to bring along my usual stimulant of choice, Monster Energy Drinks. Oh, well, probably coffee was better for my system than whatever is in the Monsters.
Coffee or no coffee, by just before three a.m. I had had enough. Three targets were in the bag, M3, M5, and M10, and three is my usual nightly goal for long exposure prime focus imaging. I shut everything down, covered the telescope and walked back to the lodge where I watched a DVD on the laptop (the animated Doctor Strange film) until my eyes began to close and I fell into a deep slumber that lasted till somewhat after eight.
Breakfast was at nine, and was the only yucky meal I experienced this spring, or, actually, that I’ve had over the last several years at the FRC. The bacon was good and the biscuits looked terrific (I admired them from afar). The problem was that instead of just doing scrambled eggs, they made a breakfast casserole. The idea was OK, but in addition to eggs, cheese, and sausage, they added in broccoli. Oh, I like broccoli…but for BREAKFAST?!
After that semi-debacle, I was off to the field to dry everything out. While the dew had not been heavy during the first part of the evening Thursday—in fact it had been amazingly light for Louisiana—the damp had come on as midnight approached, and the observing table was soaked by morning. Six years of exposure to UV at sunny star parties has made the EZ-Up less than waterproof, and it now tends to “rain” under the canopy when dew accumulates on it. I might spray it down with Scotch-Guard, or, more likely, I may just go ahead and replace it with a new EZ-Up. It’s lasted well, but has a few mechanical problems now, too.
With the refractor/mount uncovered to let them dry off in the morning Sun, I set about reconfiguring. My intention for Friday night was to go visual. For one thing, it didn’t look as if the sky would be as transparent as it had been Thursday evening. For another, I wanted to see what Hermione could do visually under dark skies. Finally, stowing the imaging-related cables, the guide scope, the guide camera, etc. would make for a quicker get-away Saturday morning. I definitely wanted to be home by noon to get in line for the free stuff at my LCS (local comic shop).
I also wanted to spend some time observing with my friend Pat’s new refractor. Pat, who planned to arrive Friday afternoon, had recently purchased an AT130 EDT (Astronomics) 130mm triplet ED scope, and I was curious to see how it would compare to my SkyWatcher refractor and to Barry’s pretty TMB 130 set up just down the field from me.
The first part of the day seemed to last forever. I spent some time surfing the Internet and reading (a graphic novel, Neal Adams’ very strange Batman Odyssey). Shortly after noon, I closed my book and trotted back to the field. As I approached, I could see Pat setting up his HEQ-5 mount and preparing to get his new telescope out of her case.
|My traveling companion...|
To say I was impressed by the AT130 would be an understatement. Beautiful, robust white tube. Nice Crayford focuser (rotatable in two places). Exquisite looking objective. The whole package just shouted “quality.” Frankly, what the Astronomics import (China) reminded me a lot of was the William Optics refractors. The 130 seemed very much the big sister of my Megrez II Fluorite (80mm). The only question in my mind was color correction. The 130 is a triplet, but doesn’t use a fluorite or synthetic fluorite element. It opts for FPL-51 glass instead of FPL-53. How would that stack up?
After the 130 was on her mount, we spent some time on the field reminiscing about the old days, about the 20 plus years we’ve been doing Deep South together. As we were sitting under my canopy shooting the breeze, Barry stopped by and mentioned his club, the Pontchartrain Astronomical Society, had some stuff to sell, including Telegizmos scope covers at great prices. Specifically, covers for refractors.
That pricked my ears up, since my old Desert Storm Cover simply will not fit over Hermione when she is on a German mount. Barry had two different sizes, including one sufficient for a 6-inch f/8 telescope, which was what I chose so I could use the cover on Big Ethel, my 6-inch achromat, as well. The Telegizmos covers seem durable, well thought out, and made it the task of just a few seconds to get the scopes under wraps at the end of the evening. Recommended.
Soon enough, the stars were beginning to wink on. With Hermione being so easy to get aligned thanks to the StarSense, I was able to spend some time helping get Pat squared away with his HEQ-5. He’d had the mount for a while, but for various reasons, including our many months of horrid weather, hadn’t been able to do much with it. In particular, he’d had little chance to play with the mount’s computer and we were anxious to give that a clean bill of health.
Got the mount, which is identical to the Orion Sirius, polar aligned using its polar borescope, and after a couple of false starts we completed a two-star goto alignment—which seemed to work better than a three-star for some reason. When we were done I was impressed at the way the mount put anything we requested in the field of the 130, which was quite steady on the mount.
The true question was about the optical quality of the new AT130 EDT. Again, I was impressed by the telescope. Despite fairly poor seeing, Jupiter showed plenty of detail and contrast was excellent. The same was true with Mars despite the fact that the Angry Red One was low when we looked at it. Certainly the scope provided beautiful wide-field views of deep sky objects.
|The observing field Friday...|
How did it stack up against my SkyWatcher and Barry’s TMB? The views in all three scopes were essentially identical. Were deep sky objects maybe a little brighter in the 130 than in my 120 thanks to those 10 extra millimeters? Maybe, but 10-millimeters isn’t much, and the difference was slight. Color correction on the FPL-51 triplet seemed pretty much the same as on my FPL-53 doublet. One other thing we concluded? The views we were getting were reminiscent of what you’d expect with a garden variety C8, and both refractors delivered satisfying views of deep sky objects.
How did the scopes hold up against Barry’s high-toned TMB? Very well, thank you. Again, the images in all three seemed more or less indistinguishable to me. Would the TMB have pulled ahead on the planets if the seeing had been better? Maybe, maybe not. It’s amazing how far the Chinese have come in the quality of their ED refractor objectives—simply amazing.
So, I spent Friday night in relaxed fashion enjoying the planets and the brighter and more spectacular deep sky wonders. I was having a great time and was sad when midnight began to approach and with it the inevitable need to pull that cursed Big Switch. I covered Hermione, returned to the Lodge, and was soon enjoying a few hours of shuteye. But only a few; I’d need to be up again at five in the stinking a.m. to pack.
Saturday was not exactly a treat, but was bearable. I was happy I’d stowed all the astrophoto gear away Friday morning, for sure. Biggest bummer was packing the EZ-Up, which was soaking wet. If Thursday had been slightly damp, Friday was well on its way to being a typical dew-heavy southeastern spring night. I got ‘er done, though, and was on the road by 8:30, just a little later than planned. The end of the Scrimmage for me was not the end of the week’s astronomy fun, however.
|FCBD at FOS Comics...|
After the drive home and FCBD and the other business I had to conduct, I was understandably tired on Saturday evening. BUT… It was obviously going to be another beautiful night under the stars and I didn’t want to waste it sitting inside watching TV. How about a trip to the club darksite then? I wasn’t about to repack Hermione and all her support gear, but that didn’t mean I'd lack telescopic horsepower.
A night like this would be perfect for Zelda, my no-frills no-goto GSO 10-inch Dobsonian. I had her, my Asus Android tablet (running SkySafari), and a box of eyepieces in the 4Runner in no more than 10-minutes and was on the road to the little country airstrip we use for our serious deep sky work.
Onsite, less than 10-minutes elapsed before I had Zelda out of the truck, on the field, and ready to rock. It wasn’t dark quite yet, but was at least dark enough to have a look at Jupiter, who was riding high in the gloaming. It wasn’t just to be an idle look, either; I had an agenda. What I wanted to know was how the Dob’s views would compare to what Pat and I had seen through the refractors.
Verdict? Pretty much a wash. The seeing was no better than it had been the previous two nights, and that no doubt prevented the 10-inch, who has a very good mirror, from pulling ahead. Yes, there were plenty of details when the seeing would settle down a little, and the Great Red Spot was easy to see, but could I see anything I hadn’t seen with the lens-scopes? No. I thought the color of the GRS was a little more saturated than in the refractors, but the difference was not striking.
On the deep sky, on M3 specifically, there was no denying Zelda left the refractors in the dust. Yes, you might say the stars had looked tinier and sharper in the 120 and 130mm scopes, but the 250mm reflector just provided more light and more stars and there was little doubt the view of the globular cluster was “better.” That wasn’t what surprised me, however. What surprised me was how well the refractors’ views of M3 actually held up against those in a much larger telescope.
What else did I look at? Not much. Shortly after astronomical twilight it became crystal clear I needed to get the heck out. Not because of Mothman, the Little Grey Dudes from Zeta Reticuli II, or the Skunk Ape, though. The big baddies who used to haunt me when I was alone at the dark site seem to have lost their power over me. That’s thanks, I suppose, to all the changes I’ve gone through in the past year.
It was the little baddies who chased me home. The mosquitoes. They were fierce, and I’d forgotten the bug spray. In my tired, fuzzy-thinking condition, I’d also forgotten to bring a jump start battery along. I had nothing to power my dew zapper gun, and my finderscope and Rigel Quick Finder would no doubt have dewed up before long.
Sunday passed uneventfully, and I thought Monday would too. Yes, there was to be a spectacular transit of Mercury across the Sun at dawn on that day, but the weathermen were unanimous that we’d have heavy clouds from the event’s start to finish. I went to bed expecting nothing.
Surprise! At dawn a look out the bedroom window revealed the sky was beautifully clear and blue. I dressed in a hurry and grabbed my most portable combo, the SkyWatcher AZ-4 alt-azimuth mount and 80mm SkyWatcher f/11.3 achromatic refractor. Slapped a Thousand Oaks solar filter on the scope and had a look with a 20mm wide-field eyepiece. There was the little bb that was Mercury. Nice, complex sunspot group too. It was quite wonderful to watch the little world’s slow progress across Sol. After Dorothy and I had taken good long looks, I even snapped a few iPhone photos through the eyepiece.
The denouement was that the weather-goobers were eventually proven correct. A couple of hours into the event we were completely clouded out, but I’d seen plenty and was happy and lucky to have seen anything. That made it a twofer for me. We’d caught the inception and the first minutes of the Venus transit in 2012 (but not much more than that thanks to violent thunderstorms) and now Merc. Cool. All in all a very good week astro-wise, and the most active and engaging one I’ve had in a while.
There are many more Scrimmage pictures on my FaceBook page.
Up next? More Messiers, that’s what.
Sunday, May 08, 2016
Issue #492: Spring Scrimmage 2016
Wha? No Blog? That’s right, friends. As usual when your faithful correspondent has been on the road, I am taking a break. You will learn about the events of the just completed Deep South Star Gaze Spring Scrimmage next week (that’s the plan anyhow) though. I have some other interesting articles lined up for the coming weeks as well, including a full report on some new software, Deep-Sky Planner 7, and the next edition of my Messier series. See ya then!
Sunday, May 01, 2016
Issue #491: The Messier VI: The Auriga Trio
How do I feel about wallpaper chasing? "Wallpaper chasing? What the heck is that?" In the ham radio game, that’s what we call the quest for awards. Contacting all 50 states. Working stations in 100 countries. The same thing goes on in amateur astronomy in the form of the Astronomical League’s Observing Clubs (one of the few things that make the League relevant for the average amateur today, I am sorry to say).
Anyhow, I’m not much of an observing award collector, but I do recommend the Messier Club. I never went on to obtain the Herschel 400 or the Herschel II certificates despite having observed all 2500 of those suckers, but I experienced a genuine feeling of accomplishment when I finally applied for and received my Honorary Messier Certificate and pin a couple of decades ago.
The Messier Club comes in two flavors. Observe 70 objects in accordance with the program’s rules and you will get a nice certificate. Do all 110 and you get the Honorary Award, which brings not just an even nicer certificate, but a handsome pin. Again, while I don’t much like chasing observing awards, I did enjoy doing this one. You might too.
Enough of that. Onward! Starting with three of the finest open clusters in the winter, the Auriga Trio, Ms 36, 37, and 38.
I am generally of the opinion that M37 is the best of the Auriga amigos, but M36 is a close second. How could it not be with the specs it has? It’s bright at magnitude 6.0 and also very compact at 10.0’ in diameter. M37 may be richer, but M36 has more bright stars. M37 tends to look like “grains of sugar on black velvet,” while M36 is “diamonds on black velvet.”
What’s it like to find without a computer? Duck soup. It is just about midway along and a degree and a half southeast of the line that connects two of the stars of Auriga’s pentagon, Beta Tauri and Theta Aurigae. Just get your scope in the general vicinity—I do that with my Rigel Quick Finder zero power sight—and you’ll immediately spot M36 in a 50mm finder (which you should have in addition to a zero power “unity” finder).
For your trouble, you get a galactic cluster you’ll find yourself staring at for quite a while even if, like me, you are not much of an open cluster fan. What you’ll see specifically is 30 – 60 Suns depending on the quality of your sky and the aperture of your telescope. For best results, I recommend a wide field eyepiece. A medium power ocular with an apparent field of at least 68 degrees will put plenty of open space around M36 and make it look just great. While the cluster is more or less round in shape, the bright stars and star chains of its central region make that area look somewhat square to me.
No, there is no denying M37 is the most beautiful member of the Auriga Trio. At magnitude 5.6, it is even brighter than M36. While at 15.0’ it is larger than the previous object, it doesn’t look that way. That is because with a very condensed (for a galactic cluster) center about 5.0’ across it almost resembles a loose globular star cluster.
Finding? This one always stymies me for some reason. It shouldn’t, but it does. It is, like M36, almost midway between that line drawn between Beta Tauri and Theta Aurigae (though a little closer to Theta). Unlike M36, however, M36 lies outside Auriga’s pentagon figure. Maybe my problem is that while M37’s combined magnitude is brighter than that of M36, it’s got fewer bright stars and is harder to see in a 50mm finder under compromised skies.
You will eventually get there, and when you do what you see will be glorious in almost any skies and with any telescope. In fact, one of the best views I’ve ever had of M37 came with my 66mm William Optics ED refractor one chilly winter's night in Chiefland, Florida over seven years ago:
I’d be remiss if I didn’t mention how well my even smaller scope, the WO 66SD, did. As ED refractor prices have come down to levels even the cheapskates among us—like Unk—can embrace, I’ve finally made friends with refractors. But mostly for imaging, not visual work, and rarely from dark sites. I’d piggybacked the 66 on the C8 mainly as an aid to spotting some of the [Herschel] 400’s large and undistinguished clusters, and it did yeoman duty there. But it did more. When I had M37 in the C8 and had gawked at it for quite a while, I finally thought to see how it looked in the little feller. In a 16mm Uwan [eyepiece], the huge field was amazing. The multitudinous stars were a glittering hailstorm, and the cluster really did look like a loose globular.
Specific notables? While the stars are, as above, dimmer looking than those of M36, they are legion. Depending on your scope/skies you will make out as many as 100 tiny sparklers. Finally, like many open clusters, M37 features a red central star. In this case, a really, really red one. The effect is, to say the least, “striking.”
|M39 with Stellarium|
M38: The Starfish Cluster
M38 is the weakest of the three Auriga star groups, but there is weak and then there is weak and M38 is still a wonder at magnitude 6.40 and 15.0’ in size. It’s relatively easy to find, too, since, like M36, it shows itself easily in a 50mm finder. Look for it 2-degrees 18’ west of M36.
What’s the most memorable thing about M38? Well, there are plenty of stars, including some fairly bright ones, brighter than most of the M37 crew, maybe about 50 in a medium aperture telescope. That’s not the big deal, though. What is is how they are arranged. Unlike M37’s stars, which form a somewhat shapeless cloud, M38’s suns are arranged in lines and streamers, and in a medium-low power eyepiece make the cluster look, yes, a lot like a cosmic starfish floating in a dark sea.
It’s good that M39 is in the summer sky, since this rather sparse open cluster frankly pales compared to the wondrous galactics of winter. Still, it’s not that bad, is certainly a little better than nearby M29, and I have always sorta liked this 39.0’ across magnitude 4.6 cluster. In fact I’ve liked it a lot and certainly recommend you stop by if you’ve never hunted it down.
Finding M39 the old-fashioned way with chart and finder scope is fairly trivial. The cluster if located a little over 9-degrees northeast of Deneb in the “blank” space between Cygnus and Cepheus. While this is actually a rich area, the cluster is large enough and bright enough that you should be able to make out its triangular shape in your finder scope without much difficulty. If you need further guidance, it forms a shallow triangle with Rho Cygni and 82 Cygni, which are close at hand.
|M41 with Stellarium|
What’s optimum for M39? I like a larger aperture telescope, 10 – 12 inches, to bring out dimmer stars and make the field look richer, but in truth, this one looked just fine from my old downtown stomping ground with the 4.25-inch Palomar Junior. There is no denying it was more impressive one night in the C11, however:
M39 is still a little low in the sky and in the worst of the light pollution to the East. Large, star-spangled beauty that fills the field of the 22mm Panoptic eyepiece. A little better in the 35mm Pan, since that places some space around the cluster. Defined by three bright stars arranged in a triangle shape filled with many, many [dimmer] stars. 30-40 stars visible even in the light pollution.
I hate to be unkind, but M40 is simply bleah. And unless you are on a quest to see ‘em all, can be skipped. You see, it’s not really a deep sky object; it’s a run of the mill double star. Yes, I know double stars are technically deep sky objects, but when most of us think “DSOs,” we think “galaxy-nebula-star cluster.”
Why is this one in the M Catalog? Old Chuck Messier had heard there was a nebula in this spot and had a look at the area of the double star now known as Winnecke 4. He could see there was no nebulosity here, but put the double in his catalog anyway since he’d gone to the trouble to measure it.
If you need/want to see M40, you’ll find it in Ursa Major 17.0’ northeast of magnitude 5.5 70 Ursae Majoris, which is a little over a degree northeast of blazing Megrez. The double is not that bright at about magnitude 9.6, but it is easy enough to see in even a 3-incher as a pair of whitish stars separated by a hair less than 1-minute of arc. A good looking double star if you like double stars (which I do).
M41, Canis Major’s only Messier, is justly famous, but this is not really a great one for telescope users. The good is that this is a bright and flashy object, a magnitude 4.5 open cluster that is routinely visible to the naked eye from a decent observing site when the Big Dog is riding high. The bad is that it is big and not highly concentrated. Its stars are bright, but there are not enough of them to really fill in an area of 39.0’, an area larger than the full moon. Any optical aid will easily turn up M41, which lies 4-degrees almost due south of Sirius.
There, a telescope will reveal a rather shapeless mass of 40 – 50 bright suns. It’s nice enough if you can get the power down and the field size up, but it is really best in giant binoculars. It is quite pretty in my good old Burgess 15x70 binocs, the glasses I’ve used the most over the last dozen years or so. The binoculars reveal a nice sprinkling of sharp little pinpricks. I really ought to try my 25x100s on M41 some night.
And there we’ll stop. A little short this time, but the next Messier is M42, the greatest of them all, and I want to be able to give it the space it deserves and requires—up to and including all or nearly all of the next Messier article.
Next time? “You’ve used Deep-Sky Planner 6 a lot over the past several years. You’ve been through four or five new telescopes with Deep-Sky Planner 6. You think nothing can replace Deep-Sky Planner 6. Then you look in the mailbox and there’s a DVD containing Deep-Sky Planner 7. And you break into your happy dance.”
